Kenbotong 2,4 - TDJ-2325SPL9A

Price : $42

Square grid antenna is designed for the spread spectrum system, the dimension is in complied with the plot of feed reflector, which ensure the antenna works in the best state. This antenna features high gain, long working distance, light weight, compact structure and good command in wind resistance.

Electrical Specifications
Model TDJ-2400A
Frequency Range–MHz 2400-2483
Bandwidth-MHz 83
Gain-dBi 24
Horizontal Beamwidth -° 10
Vertical Beamwidth -° 14
F/B ratio-dB =31
VSWR =1.5
Input Impedance -O 50
Polarization Vertical or Horizontal
Maximum Power -W 100
Connector N Female or Customization
Mechanical Specifications
Dimensions-m 0.6×0.9 Weight-kg 2.5 Mounting Mast Diameter-mm ?40~50
2.4 GHz 24 dBi Parabolic Grid Antenna
